FERMAT CZ

Year: 2007 Dimensions of table working surface 1400 x 360 mm Travel X-axis 1000 mm Travel Y-axis 300 mm Travel Z-axis 420 mm Spindle taper ISO 50 . Main motor power 7 kW Machine weight 2750 kg Machine dimensions l x w x h 3410 x 2400 x 2100 mm Spindle speed 1 - 2000 /min. The machine is in good technical condition, under power, after agreement is possible to test it. Including accessories.

Year: 2008 Max. weight of workpiece 5000 kg Robotic welding system CLOOS: - ROBOT ROMAT 350 (Rotol II) - WPV-DP-10 000 (positioner load capacity 1000kg, workpiece diameter 4000mm) - WPV-50kN (positioner load capacity 5000kg, workpiece diameter 4800mm) - 2xGLC 603 Quinto ( Singel MRW 500 + Tandem ZMW 800) New control system installed in 2023

Year: 2015 Max. length of workpiece 3050 mm Max. workpiece width 2100 mm Max. thickness cutting material 35/200 mm Type of cutting Combinated In very good condition. Plasma ForCut 263WDM HPR. Suction TIGEMA TIG FS 6700/112/C. Compressor InAirCom BAC 5-10-270. 3D including tube cutter ø 50-400mm/3000mm.

Year: 1975 Diameter of working spindle 90 mm Travel X-axis 1000 mm Travel Y-axis 900 mm Spindle speed 0 - 1400 /min. Cooling through spindle NO Spindle travel - W axis 710 mm Travel Z-axis 800 mm Tool magazine NO Spindle taper MORSE 5 . Main motor power 7,5 kW Table dimensions 1000 x 1120 mm Machine dimensions l x w x h 3900 x 2500 x 2650 mm Machine weight 9000 kg The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2006 Work surface 3070x1660 mm Rated deformation force press 18 t Travel X-axis 3070 mm Travel Y-axis 1660 mm Max. plate thickness 6,4 mm Tool magazine YES Number of positions in magazine 22 Machine weight 14850 kg Machine dimensions l x w x h 7600x6700x2230 mm The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2005 Control system Heidenhain TNC 530 Clamping area of table 600x1000 mm Travel X-axis 630 mm Travel Y-axis 560 mm Travel Z-axis 560 mm Spindle speed 0 - 18000 /min. Number of driven axes 5 Cooling through spindle YES Spindle taper HSK 63 . Table diameter 600 mm Number of positions in magazine 24 Main motor power 15/10 kW Max. weight of workpiece 500 kg The machine is in very good technical condition and can be tested under power . Worked approx. 27000 hours. There are accessories for the machine. I recommend a visit to our warehouse in Brno.

Year: 2007 Control system Heidenhain TNC 530 Diameter of working spindle 110 mm Travel X-axis 2500 mm Travel Y-axis 1500 mm Spindle speed 0 - 2500 /min. Cooling through spindle YES Pressure of cooling 20 bar Spindle travel - W axis 550 mm Travel Z-axis 1200 mm Tool magazine NO Spindle taper ISO 50 . Table dimensions 1250x1400 mm Max. load of table 5000 kg Max. torque of spindle 1300 Nm Machine dimensions l x w x h 5663 x 4775 x 4078 mm Machine weight 22000 kg The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2008 Control system Traub TX 8 i Turn table diameter 680 mm Turning lenght 1000 mm Sloping bed YES Y axis NO Counterspindle NO Spindle bore 100 mm Milling head NO Driven Tools YES Number of tool positions (driven) 12/12 Bar loader NO Travel X-axis 320 mm Travel Z-axis 1070 mm Axis C 0,001 ° X-axis rapid feed 15 m/min Z-axis rapid feed 20 m/min Spindle speed 1 - 2240 /min. Max. torque of spindle 682 Nm Main motor power 31 kW Speed driven tools 1 - 3150 /min Machine weight 6800 kg Machine dimensions l x w x h 5500x2300x2150 mm The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2014 Control system Heidenhain TNC 530 Clamping area of table 600 mm Travel X-axis 800 mm Travel Y-axis 700 mm Travel Z-axis 610 mm Spindle speed 20 - 15000 /min. Number of driven axes 5 Cooling through spindle YES Pressure of cooling 20 bar Spindle taper ISO 40 . Max. weight of workpiece 300 kg Main motor power 25 kW Rapid feed 32,32,16 m/min Tool magazine YES Number of positions in magazine 30 Machine weight 8750 kg Machine dimensions l x w x h 3710x2530x3230 mm The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2004 Control system Fanuc Turn table diameter 380 mm Turning lenght mm Travel X-axis 151 mm Travel Z-axis 339 mm Swing over cross slide 290 mm Spindle speed 20 - 6000 /min. Machine weight 4200 kg Main motor power 7,5 kW Bar loader NO Machine dimensions l x w x h 2885/3865x1720x1670 mm The machine is in good condition.
