CNC Drehmaschinen

Year: 2012 Control system Fanuc 32i - B Turn table diameter 20 mm Turning lenght 250 mm Sloping bed NO Y axis YES Counterspindle NO Spindle bore mm Milling head NO Driven Tools YES Number of tool positions (driven) 39/15 Bar loader YES Spindle speed 0 - 12000 /min. Machine weight 3300 kg Machine dimensions l x w x h 2100,0 × 1200,0 × 1900,0 mm number of axes: 6 linear + 2x C-axis Range of cylindrical rod diameters (min./max.) - 3-20 Work piece length: - fixed guide sleeve - 250 mm - motorized guide sleeve - 210 mm - without guide sleeve - 45 mm Power of the main spindle drive - 2.2 / 3.7 kW Spindle speed - 12,000 rpm. Counterspindle drive power - 1.5 / 2.2 kW Cross-section of the shank of turning tools - 16x16 mm Rotational speed of driven tools - 8,000 rpm. Drive power for tools driven on the front support - 0.75 kW Drive power for tools driven on the rear support - 1 kW Drive power of driven tools for processing the other side - 0.75 kW Oil pan capacity - 165 liters Oil pump powe

Year: 2015 Control system Mitsubishi M 70 V Turn table diameter 600 mm Turning lenght 3000 mm Sloping bed NO Y axis NO Counterspindle NO Spindle bore 104 mm Milling head NO Driven Tools YES Bar loader NO Swing over bed 600 mm Swing over cross slide 310 mm Travel Z-axis 2800 mm Axis C 0,001 ° Spindle speed 10 - 2500 /min. Turret head YES Machine weight 5150 kg Machine dimensions l x w x h 5840x1888x2050 mm The machine is in excelent condition. Possible to test under power.

Year: 2008 Control system Siemens Sinumerik 840 D Turn table diameter 400 mm Turning lenght 600 mm Sloping bed YES Y axis YES Travel Y-axis 64mm (+/- 32mm) mm Counterspindle YES Spindle bore 50 mm Milling head NO Driven Tools YES Number of tool positions (driven) 12 Bar loader YES Travel X-axis 160 mm X-axis rapid feed 60 m/min Swing over bed 400 mm Distance between centres 615 mm Spindle speed 0 - 6000 /min. Main motor power 16 kW Spindle taper VDI 30 . Machine weight 3 700 kg Very good technical condition. Possible to test it.

Year: 2013 Control system Fanuc 31i - B5 Turn table diameter 10 mm Turning lenght 100 mm Sloping bed YES Y axis YES Counterspindle YES Spindle bore 10 mm Milling head NO Driven Tools YES Bar loader YES Spindle speed 0 - 14000 /min. The machine is in excelent condition. Possible to test under power. Bar feeder LNS Tryton.

Year: 2015 Control system Mazatrol MATRIX 2 Turn table diameter 320 mm Turning lenght 180 mm Sloping bed NO Y axis NO Counterspindle YES Spindle bore 51 mm Milling head NO Driven Tools NO Bar loader NO Machine weight 7900 kg Machine dimensions l x w x h 3570x1795x2090 mm Swing over bed 320 mm Spindle speed 1 - 5000 /min. The machine is in a good technical condition. Under power. It can be tested.

Year: 2017 Control system OKUMA OSP-P300LA Turn table diameter 580 mm Turning lenght 950 mm Sloping bed YES Y axis YES Travel Y-axis (lathe) 120 mm Counterspindle NO Spindle bore 91 mm Milling head NO Driven Tools YES Number of tool positions (driven) 12/12 Bar loader NO Travel X-axis 260 mm Travel Z-axis 510 mm Spindle speed 0 - 5000 /min. Speed driven tools 45 - 6000 /min X-axis rapid feed 25 m/min Z-axis rapid feed 30 m/min Y-axis rapid feed 12,5 m/min Axis C 360 ° Main motor power 22 kW Machine dimensions l x w x h 3420 x 2041x 2444 mm Machine weight 6600 kg The machine is in a good technical condition. Under power. It can be tested.

Year: 2017 Control system OKUMA OSP-P300LA Turn table diameter 580 mm Turning lenght 950 mm Sloping bed YES Y axis YES Travel Y-axis (lathe) 120 mm Counterspindle NO Spindle bore 91 mm Milling head NO Driven Tools YES Number of tool positions (driven) 12/12 Bar loader NO Travel X-axis 260 mm Travel Z-axis 510 mm Spindle speed 0 - 5000 /min. Speed driven tools 45 - 6000 /min X-axis rapid feed 25 m/min Z-axis rapid feed 30 m/min Y-axis rapid feed 12,5 m/min Axis C 360 ° Main motor power 22 kW Machine dimensions l x w x h 3420 x 2041x 2444 mm Machine weight 6600 kg The machine is in a good technical condition. Under power. It can be tested.

Year: 2002 Control system Mazatrol 640 T Machine dimensions l x w x h 3680 x 2460 x 1740 mm mm Spindle bore 40 mm Main motor power 31 kW Machine weight 2720 kg Travel Z-axis 540 mm Travel X-axis 155 mm Spindle speed 1 - 6000 /min. The machine is in good condition, can be tested.

Year: 2004 Control system Haas Turn table diameter 241 mm Turning lenght 508 mm Sloping bed YES Spindle bore 76 mm Turret head YES Swing over bed 584 mm Distance between centres 610 mm Machine weight 4100 kg Machine dimensions l x w x h 3500x1900x1900 mm Spindle speed 0 - 3000 /min. The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2017 Control system Fanuc i Series Turn table diameter 600 mm Turning lenght 330 mm Sloping bed YES Spindle bore 61 mm Turret head YES Swing over bed 600 mm Swing over cross slide 400 mm Travel X-axis 205 mm Travel Z-axis 340 mm X-axis rapid feed 30 m/min Z-axis rapid feed 36 m/min Spindle speed 0 - 6000 /min. Max. torque of spindle 127 Nm Main motor power 11/15 kW The machine is in excelent condition. Possible to test under power.
