BAYKAL HGL 3100x6 - Plate Shears

Control system DelemDA - 56 s Bending power 160t Bending length 3700mm Number of driven axes 4 Lower compensation movement Type of press drive Hydraulic Max. ram stroke 260mm Main motor power 15kW Machine weight 10700kg Machine dimensions l x w x h 4750x1850x2660mm The machine is in good technical condition, under power, after agreement it is possible to test it. Video: https://www.youtube.com/watch?v=Pj3_2gF-6tk

Rated deformation force press 15 t Dimensions of table working surface mm Ram stroke 220 mm Machine dimensions l x w x h 1050x690x1400 mm Machine weight 450 kg The machine is in good technical condition, under power.

Rated deformation force press 10 t Dimensions of table working surface 450x400 mm Main motor power 1,6 kW Machine dimensions l x w x h 1300x1000x2220 mm Machine weight 1100 kg The machine is in good technical condition, under power.

DescriptionNFPP - 300 ton cold forming press + 180 ton hot pressLine consisting of:- hot press calibrating material thickness (180T at 210 bar) maximum opening height 300mm, closing speed 30mm/s net weight 27 tons- forming press (300T at 300 bar) maximum opening height 1100mm, max closing speed 400mm/s net weight 52 tons, minimum tool dimension 1730x1000x950, maximum tool weight 14 tons- abb irb 6700 robot with running track for autonomous operation of press loading from raw material storage.The line will be ready for loading in mid-May 2025

Year: 1996 Max. length of cutting: 3150 mm Max. plate thickness: 6,3 mm Drive type of shears: Mechanical Machine dimensions l x w x h: 3800 x 2160 x 1630 mm Machine weight: 8500 kg The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2014 Max. diameter of bended tube 130 mm Thickness of tube-wall 5 mm Drive type bender electro-mechanical Main motor power 30 kW Machine weight 12000 kg Machine dimensions l x w x h 7200x2150x2100 mm under power, possibility to test, in good condition Working hours of the machine 2.700 Cooling Tools 63,5 x 10 76,1 x 10

Year: 2014 Max. length of workpiece 3050 mm Max. workpiece width 2100 mm Max. thickness cutting material 140 mm Type of cutting Autogen The machine is in very good technical condition, possible to test under power.

Year: 2016 Max. length of workpiece 3050 mm Max. workpiece width 1525 mm Max. plate thickness 19 mm Power of laser 2500 W Fiber NO Travel Z-axis 300 mm Axis A 360 ° Axis B 135 ° Axis C 360 ° Control system Mazatrol Machine dimensions l x w x h 9800x5000x2300 mm Machine weight 14500 kg 2D / 3D laser cutter. The machine is in excellent technical condition and can be tested. Mazak FX control system. Accessories, options: program transfer software, side diffuser, thru holder manual ncrotary table (20-285 mm), profilling retry for 2D processing, 7,5” torch for 2D (W/O lens), dust collector, laser card cam pack 3.

Year: 2015 Max. length of workpiece : 3000 mm Max. workpiece width : 1500 mm Max. plate thickness : 12 mm Power of laser : 750 W The machine is in good condition. Possible to test it.

Year: 2015 Rated deformation force press 700 t Dimensions of table working surface 2500x1500 mm Ram stroke 500 mm Shutheight 1200 mm Ram dimensions 2400x1000 mm Clearance between columns 2500 mm Control system Siemens Force of bottom ejector 234 t Downstroke 200 mm Machine weight 52000 kg Machine dimensions l x w x h 5150x2870x4710 mm The machine is in excelent condition. Possible to test under power. Control system Siemens SIMATIC HMI PANEL – KTP 900 BASIC, BOOTLOADER verze: V02.03
