FERMAT CZ

Turn table diameter 400 mm Turning lenght 760 mm Sloping bed NO Spindle bore 54 mm Turret head NO Swing over cross slide 215 mm Spindle speed 150 - 2500 /min. Machine dimensions l x w x h 2080x1000x1800 mm Machine weight 1250 kg The machine is in good technical condition, under power.

Year: 1979 Swing over bed 710 mm Distance between centres 2000 mm Max. weight of workpiece 850 kg Swing over cross slide 420 mm Spindle speed 10 - 1000 /min. Main motor power 7,5 kW Machine weight 3000 kg Machine dimensions l x w x h 4000x1440x1560 mm

Year: 1994 Swing over bed 630 mm Distance between centres 2000 mm Max. weight of workpiece kg Swing over cross slide 340 mm Main motor power 7.5 kW Machine dimensions l x w x h 4000 x 1400 x 1520 mm Machine weight 2960 kg

Year: 2009 Max. dimensions of workpiece 530x320x200 mm Max. weight of workpiece 70 kg Machine weight 3000 kg Machine dimensions l x w x h 2800x1750x2400 mm The machine is in excelent condition. Possible to test under power. Cleaning process - dip-degreasing with solvent alternatively with ultrasonic. - Immersion - Intermediate drying - Vapour degreasing - Vacuum drying All steps alternatively with basket motion Batch dimensions 530 x 320 x 200 mm Performance 8-10 batches/h (normal programme) Batch weight max. 70 kg Solvent hydrocarbon, modified alcohol Content Solvent approx. 450 litres Electrical output: Heat output 33 kW Motor output 13 kW Cooling output approx. 15 kW power requirement approx. 51 kW / 90 A Operating voltage 400 V / 50 Hz / 3/N/PE Pressurised air approx. 6 bar Amount of exhaust airapprox. 63 m3/h

Year: 1996 Max. length of cutting: 3150 mm Max. plate thickness: 6,3 mm Drive type of shears: Mechanical Machine dimensions l x w x h: 3800 x 2160 x 1630 mm Machine weight: 8500 kg The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2014 Max. diameter of bended tube 130 mm Thickness of tube-wall 5 mm Drive type bender electro-mechanical Main motor power 30 kW Machine weight 12000 kg Machine dimensions l x w x h 7200x2150x2100 mm under power, possibility to test, in good condition Working hours of the machine 2.700 Cooling Tools 63,5 x 10 76,1 x 10

Year: 2006 Travel X-axis 350 mm Travel Y-axis 250 mm Travel Z-axis 250 mm Machine weight 4000 kg Machine dimensions l x w x h 1490x1050x2070 mm Max. weight of workpiece 1000 kg Max. length of workpiece 800 mm Max. workpiece height 320 mm Max. workpiece width 500 mm Work surface 600x400 mm The machine is in a good technical condition. Under power. It can be tested.

Year: 2006 Max. diameter of the cut material mm Max. travel of table 2700 mm Max. thickness cutting material 80 mm Table dimensions 1800x3000 mm Main motor power 11 kW The machine is in a good technical condition. Under power. It can be tested.

Year: 2014 Max. length of workpiece 3050 mm Max. workpiece width 2100 mm Max. thickness cutting material 140 mm Type of cutting Autogen The machine is in very good technical condition, possible to test under power.

Year: 2016 Max. length of workpiece 3050 mm Max. workpiece width 1525 mm Max. plate thickness 19 mm Power of laser 2500 W Fiber NO Travel Z-axis 300 mm Axis A 360 ° Axis B 135 ° Axis C 360 ° Control system Mazatrol Machine dimensions l x w x h 9800x5000x2300 mm Machine weight 14500 kg 2D / 3D laser cutter. The machine is in excellent technical condition and can be tested. Mazak FX control system. Accessories, options: program transfer software, side diffuser, thru holder manual ncrotary table (20-285 mm), profilling retry for 2D processing, 7,5” torch for 2D (W/O lens), dust collector, laser card cam pack 3.
