VAIOCS 1 G
1/3
CONTACT
Company
FERMAT CZContact person
Barbora Teplárková
Phone
+420778547838Mobile
+420778547838
Country
Czech RepublicMACHINE DATA
Ad No
2552
Price
Ask Price
Brand
Emo
Year / Model
2009 / VAIOCS 1 G
Owner
From Seller
Status
Used
Ad Date
15.05.2025
DESCRIPTION
Year: 2009
Max. dimensions of workpiece 530x320x200 mm
Max. weight of workpiece 70 kg
Machine weight 3000 kg
Machine dimensions l x w x h 2800x1750x2400 mm
The machine is in excelent condition. Possible to test under power.
Cleaning process - dip-degreasing with solvent alternatively with ultrasonic.
- Immersion
- Intermediate drying
- Vapour degreasing
- Vacuum drying
All steps alternatively with basket motion
Batch dimensions 530 x 320 x 200 mm
Performance 8-10 batches/h (normal programme)
Batch weight max. 70 kg
Solvent hydrocarbon, modified alcohol
Content Solvent approx. 450 litres
Electrical output:
Heat output 33 kW
Motor output 13 kW
Cooling output approx. 15 kW
power requirement approx. 51 kW / 90 A
Operating voltage 400 V / 50 Hz / 3/N/PE
Pressurised air approx. 6 bar
Amount of exhaust airapprox. 63 m3/h
