Year: 2012 Control system Fanuc 32i - B Turn table diameter 20 mm Turning lenght 250 mm Sloping bed NO Y axis YES Counterspindle NO Spindle bore mm Milling head NO Driven Tools YES Number of tool positions (driven) 39/15 Bar loader YES Spindle speed 0 - 12000 /min. Machine weight 3300 kg Machine dimensions l x w x h 2100,0 × 1200,0 × 1900,0 mm number of axes: 6 linear + 2x C-axis Range of cylindrical rod diameters (min./max.) - 3-20 Work piece length: - fixed guide sleeve - 250 mm - motorized guide sleeve - 210 mm - without guide sleeve - 45 mm Power of the main spindle drive - 2.2 / 3.7 kW Spindle speed - 12,000 rpm. Counterspindle drive power - 1.5 / 2.2 kW Cross-section of the shank of turning tools - 16x16 mm Rotational speed of driven tools - 8,000 rpm. Drive power for tools driven on the front support - 0.75 kW Drive power for tools driven on the rear support - 1 kW Drive power of driven tools for processing the other side - 0.75 kW Oil pan capacity - 165 liters Oil pump powe

Year: 2013 Control system Fanuc 31i - B5 Turn table diameter 10 mm Turning lenght 100 mm Sloping bed YES Y axis YES Counterspindle YES Spindle bore 10 mm Milling head NO Driven Tools YES Bar loader YES Spindle speed 0 - 14000 /min. The machine is in excelent condition. Possible to test under power. Bar feeder LNS Tryton.

Year: 2017 Control system Fanuc i Series Turn table diameter 350 mm Turning lenght 330 mm Sloping bed YES Spindle bore 76 mm Turret head YES Machine weight 2750 kg Travel X-axis 300 mm Travel Z-axis 360 mm Chuck diameter 210 mm Spindle speed 1 - 4500 /min. Machine dimensions l x w x h 2350x1595x1693 mm The machine is in excellent condition, little worked, possible inspection.

Year: 2010 Control system Siemens 810 D Turn table diameter 160 mm Turning lenght 450 mm Sloping bed YES Y axis NO Counterspindle NO Spindle bore 51 mm Milling head NO Driven Tools YES Number of tool positions (driven) 12/6 Bar loader Travel X-axis 160 mm Travel Z-axis 450 mm Spindle speed 1 - 5000 /min. Machine dimensions l x w x h 4228 x 3115 x 2153 mm Machine weight 3800 kg Machine in good condition.It has universal chuck, toolholder for knife, borer and driven tools 2 axial and 2 radial.

Year: 2015 Control system Siemens Sinumerik 840 D Clamping area of table 2X D 500 mm Travel X-axis 830 mm Travel Y-axis 630 mm Travel Z-axis 630 mm Spindle speed 0 - 20000 /min. Number of driven axes 5 Cooling through spindle NO Spindle taper HSK-A63 . Tool magazine YES Number of positions in magazine 2 x 30 Machine weight 18500 kg Machine dimensions l x w x h 7000x3200x3500 mm

Year: 2010 Control system Heidenhain TNC 530 Clamping area of table 1200x600 mm Travel X-axis 1020 mm Travel Y-axis 610 mm Travel Z-axis 610 mm Spindle speed 10 - 12000 /min. Number of driven axes 3 Cooling through spindle YES Pressure of cooling 20 bar Spindle taper SK 40 . Max. weight of workpiece 500 kg Main motor power 22 kW Rapid feed 40,40,36 m/min Tool magazine YES Number of positions in magazine 30 Machine weight 6970 kg Machine dimensions l x w x h 2920x2820x2860 mm The machine is in good technical condition, under power, after agreement is possible to test it.

Year: 2015 Control system Mazatrol MATRIX 2 Clamping area of table 1300x550 mm Travel X-axis 1050 mm Travel Y-axis 530 mm Travel Z-axis 510 mm Spindle speed 10 - 12000 /min. Number of driven axes 3 Cooling through spindle YES Pressure of cooling 15 bar Spindle taper ISO 40 . Max. load of table 1200 kg Tool magazine YES Number of positions in magazine 30 Number of pallets 2 Machine weight 7700 kg The machine is in very good technical condition, under power, after agreement is possible to test it.

Year: 2025 Control system Heidenhain TNC 640 Clamping area of table 1200 x 500 mm Travel X-axis 1040 mm Travel Y-axis 540 mm Travel Z-axis 600 mm Spindle speed 12000 - /min. Number of driven axes 3 Cooling through spindle YES Pressure of cooling 25 bar Spindle taper SK 40 . Max. weight of workpiece 800 kg Tool magazine YES Number of positions in magazine 24 Machine dimensions l x w x h 2900 x 2420 x 2840 mm Machine weight 6400 kg Linear roller guide in all axes. Articulated chip conveyor. Heidenhain direct absolute metering in all axes. Fully covering the machine. 19 color touch monitor GEN3 digital AC drives with regenerative power supply module. HR 510 handwheel. Preparation for 4 and 5 people. Preparation for probes.

Diameter of working spindle 100 mm Travel X-axis 1600 mm Travel Y-axis 1120 mm Spindle speed 7 - 1120 /min. Cooling through spindle NO Spindle travel - W axis 900 mm Travel Z-axis 1250 mm Tool magazine NO Spindle taper ISO 50 . Max. load of table 3000 kg Machine dimensions l x w x h 6710 x 3450 x 3000 mm Machine weight 14000 kg Main motor power 11 kW Total input 17 kVA Clamping area of table 1250 x 1250 mm Face plate diameter 600 mm Max. diameter of face turning 900 mm Machine is overhauled. Hand-controlling horizontal borer machine with fixed stand and cross-adjustable table. The machine is in the following version: X, Z, Y ground, traverse milled and undercut, more precisely glued with special material with sliding properties (Turcite, GS-super fluid, etc.), wedges ground and scraped. The worktable surface is grinded and scraped (reinovation of grooves as required). The X and Y axes are equipped with trapezoidal screws with nuts - placed in bearing housings. Headstock - Gearwheel be

Year: 2008 Control system Siemens Sinumerik 840 D Max. diameter of workpiece 3000 mm Clamping diameter of rotary table 2800 mm Max. load of table 18000 kg Max. workpiece height 1800 mm Ram travel (Z) 1400 mm Ram size 320 mm Driven Tools NO Tool magazine YES Number of positions in magazine 12 Main motor power 50 kW Machine weight 40000 kg under power in very good condition
