Cnc Vertical Machining Center CHIRON FZ 08 KS Magnum

Control system Heidenhain TNC 530 Diameter of working spindle 130 mm Travel X-axis 4000 mm Travel Y-axis 2000 mm Spindle speed 10 - 3000 /min. Cooling through spindle YES Pressure of cooling 20 bar Spindle travel - W axis 730 mm Travel Z-axis 1700 mm Tool magazine NO Spindle taper ISO 50 . Table dimensions 1800x2200 mm Main motor power 41 kW The machine is in good technical condition; testing under power is possible. Accessories: workpiece probe, manual head, flange

Year: 2024 Control system Siemens Sinumerik 840D Sl Clamping area of table 1400 x 1000 mm Travel X-axis 1335 mm Travel Y-axis 1250 mm Travel Z-axis 900 mm Spindle speed 0 - 20000 /min. Number of driven axes Cooling through spindle YES Pressure of cooling 40 bar Spindle taper HSK A 63 . Axis A +120° -120° ° Axis C 360 ° Max. load of table 2000 kg Tool magazine YES Number of positions in magazine 60 Rapid traverse (X, Y, Z): 40 m/min Table type: NC swivel rotary table Table clamping surface: 1400 mm x 1000 mm (integrated C-axis with a table plate of 1250 x 1000 mm) Swivel range (A-axis): +120° to -120° Rotation range (C-axis): 360° Max. workpiece dimensions: Machinable diameter 1250 mm, height 790 mm Spindle type: Motor spindle speedMASTER with HSK-A 63 taper (nebo interface) Speed: Max. 20,000 rpm (this is an optional feature selected in this quote, standard is 15,000 rpm) Output / Power: 35 kW (at 40% duty cycle) / 25 kW (at 100% duty cycle) Tool magazine: Vertical chain magazine

Year: 1966 Swing over bed 3000 mm Max. weight of workpiece 2500 kg The machine is in good technical condition, can be tested under power. Accessories: copying attachment.

Year: 2018 Control system Fanuc 0i-TF Turn table diameter 450 mm Turning lenght 600 mm Sloping bed YES Spindle bore 86 mm Turret head YES Swing over bed 580 mm Travel X-axis 240 mm Travel Z-axis 600 mm Spindle speed 10 - 4000 /min. Main motor power 15/11 kW Rapid feed 20 m/min Machine weight 4500 kg Machine dimensions l x w x h 3525x1851x1862 mm Excellent technical condition, testing possible. Includes: tool probe

Year: 2014 Control system Heidenhain TNC 530 Clamping area of table 1800 (1600x2500) mm Travel X-axis 2300 mm Travel Y-axis 1400 mm Travel Z-axis 1050 mm Spindle speed 10 - 10000 /min. Number of driven axes 5 Cooling through spindle YES Pressure of cooling 40 bar Spindle taper HSK-A100 . Max. weight of workpiece 10000/5000 kg Max. torque of spindle 130/150 Nm Axis C 360 ° Axis B ±110 ° Rapid feed 50 m/min Tool magazine YES Number of positions in magazine 48 Machine weight 32000 kg Machine dimensions l x w x h 6640x6000x4800 mm The machine is in good technical condition, under power, after agreement it is possible to test it. Accessories: tool and workpiece probe

Year: 2007 Control system Siemens Sinumerik 840 D Max. diameter of grinding 630 mm Max. length of grinding 3000 mm Max. weight of workpiece 1200 kg Total input 56 kVA Machine weight 12700 kg Machine dimensions l x w x h 9900x2980x1875 mm The machine is in good technical condition, under power, after agreement it is possible to test it. Video: https://www.youtube.com/watch?v=ly4WISAUKkM

Distance between centres 500 mm Max. weight of workpiece 2000 kg

Year: 2003 Control system Heidenhain TNC 530 Clamping area of table 1500x1050 mm Travel X-axis 1250 mm Travel Y-axis 880 mm Travel Z-axis 800 mm Spindle speed 20 - 8000 /min. Number of driven axes 3 Cooling through spindle YES Pressure of cooling 40 bar Spindle taper SK 40 . Tool magazine YES Number of positions in magazine 30 Max. weight of workpiece 2500 kg Machine after a complete overhaul in 2016. New spindle installed in September 2025. Equipped with a workpiece probe and a Blum laser tool setter. Very good technical condition. Can be tested under power. Video: https://youtu.be/TaAS5iMCII0

Year: 1991 Diameter of working spindle 100 mm Travel X-axis 1600 mm Travel Y-axis 1120 mm Spindle speed 0 - 1200 /min. Cooling through spindle NO Spindle travel - W axis 900 mm Travel Z-axis 1250 mm Tool magazine NO Spindle taper ISO 50 . Clamping area of table 1250 x 1250 mm Max. load of table 3000 kg Main motor power 11 kW Machine dimensions l x w x h 6710 x 3450 x 3000 mm Machine weight 14 000 kg The machine is in very good technical condition, under power, and can be tested.

Year: 2010 Control system Fanuc 18i-TB Turn table diameter 20 mm Turning lenght 165 mm Sloping bed NO Y axis YES Counterspindle YES Spindle bore 31 mm Milling head NO Driven Tools YES Bar loader YES Spindle speed 0 - 8000 /min. Total input 6 kVA Machine weight 2550 kg Machine dimensions l x w x h 2200x1200x2000 mm The machine is in very good technical condition and can be tested. Accessories: LNS EXPRESS 220 feeder
